Orbital Shaker Incubator

Orbital Shaker / Rotary Shakers

Orbital Shakers are widely used in microbiology, chemistry, immunology, biochemistry and molecular biology for basic mixing applications and bacterial suspensions. These variable speed shakers comprise of shaking platform, speed regulator and timer to adjust duration of orbital motion. These machines are often light weight and benchtop in design.
We are orbital shaker manufacturers and suppliers in India and make orbital shakers in different platform sizes to meet demands of shaking small as well as large number of flasks of 100 ml, 250ml, 500ml and 1000 ml. Our laboratory orbital shaker machines have analog speed regulators to control speed from 5 to 400 rpm. Platform is made of stainless steel; clamps are made of either unbreakable plastic or stainless steel. The shaking mechanism is the heart of machine and made of a heavy duty brushless motor which features smooth and jerk less orbital motion. The housing is made of a thick sheet of mild steel duly powder coated. RPM display and digital timer are both optional accessories and fitted on special request of customer at extra price.

Enquire Now   Download PDF

Share:
TECHNICAL SPECIFICATIONS
Motion Orbital
Platform MOC Stainless steel
Clamp MO SS or Unbreakable plastic
Housing Painted MS
RPM 5 – 400 RPM
Amplitude 25 mm
RPM Controller Digital LCD Controller.
Shaking mechanism Brushless motor
Construction Heavy iron angled frame Powder Coated.
Power supply 220 Volts 50Hz

STANDARD SIZES & DIMENSIONS
Model Platform size No. of flasks
DQ-OS-01 12 x 12 Inch
  • 9 x 250 ml or
  • 9 x 500 ml or
  • 4 x 1000 ml or
  • 16 x 100 ml
DQ-OS-02 18 x 18 Inch
  • 16 x 250 ml or
  • 16 x 500 ml or
  • 9 x 1000 ml or
  • 25 x 100 ml
DQ-OS-03 22 x 22 Inch
  • 25 x 250 ml or
  • 25 x 500 ml or
  • 16 x 1000 ml or
  • 36 x 100 ml
DQ-OS-04 26 x 26 Inch
  • 36 x 250 ml or
  • 36 x 500 ml or
  • 25 x 1000 ml or
  • 49 x 100 ml
