Stainless Steel Laboratory Oven
Digiqual Systems Manufacturers Stainless Steel ( SS ) Laboratory Hot Air Oven . Inter space in between the outer and middle wall is tightly packed with special grade glass wool. the outside skin temperature will be around 20 top 30 degs C above ambient. The oven will be provided with required number of adjustable Trays.
In Stainless Steel ( SS ) Hot Air Oven Electric Tubular Air Heaters with SS Fins is provided which will have much longer life. The Heating system will be designed for max.250 degs C operation with uniform temperature all over the Oven Chamber.
In Stainless Steel ( SS ) Laboratory Hot Air Oven An Air circulation fan with a suitable motor mounted at the back for ensuring uniform temperature throughout the heating chamber. The temperature inside the chamber is controlled by a Digital Temperature Indicator cum controller which will work in conjunction with a Thermocouple.
| Technical Specifications | ||
|---|---|---|
| Temperature Range | Ambient +5°C to 250°C | |
| Temperature Accuracy | 5°C | |
| Operating Voltage | 230 Voltage | |
| Specifications | ||
|---|---|---|
| Chamber Size | Trays | Power Rating kw |
| 300 X 300 X 300 | 2 | 1.0 |
| 355 X 355 X 355 | 2 | 1.2 |
| 455 X 455 X 455 | 2 | 1.8 |
| 455 X 455 X 605 | 2 | 2.4 |
| 605 X 605 X 605 | 3 | 3.0 |
| 605 X 455 X 910 | 3 | 4.0 |
| 605 X 605 X 910 | 3 | 4.0 |
